Fairfield Circuitry 900 Fuzz Pedal

And when things are combined, is anything lost? And when something is lost, will there ever be more?

But what is the gain?

The ~900 is a ferocious fuzz pedal featuring two cascading JFET gain stages. Tracing its lineage back to our discontinued Four Eyes Fuzz, it offers a very wide range of gain, adds delicious harmonics and, if given the opportunity, will slap the ice cream cone right out of your hand.

The four highly interactive controls are:

INPUT - input gain
FUZZ - second stage gain
BIAS - second stage bias and gain
VOLUME - output level

All Fuzzes
Are Friends

TECHNICALS
• true bypass
• dimensions 2.7" x 4.4"
• input impedance 1MΩ
• output impedance <5kΩ
• power supply 9 - 9.6VDC
• current draw 10mA @ 9.6VDC

CONNECTIONS
IN
1/4" Instrument input

OUT
1/4" Output

9V
2.1mm 9VDC center-negative tip, at least 10mA
